UK/EU Ship 2024 OBDSTAR DC706 DC 706 ECU Tool Full Version ECM+TCM+BODY ECU Clone by OBD or BENCH for Cars and Motorcycles

DC706 Supported ECU Manufacturers:



ACDELCO
ALPS
ATE
AUTOLIV
BOSCH
CONTINENTAL
DELPHI
DENSO
DENSO DECE1C
EFI
GETRAG
GM
JC
KEFICO
LEAR
MAGNETI MARELLI
Marelli
SIEMENS
SIEMENS/CONTINENTAL
SIMTEC
TEMIC
VALEO
VISTEON
YAZAKI
ZF





ASTON MARTIN

BMW

FAW

FCA(ALFA ROMEO, CHRYSLER, DODGE, FIAT...)

FORD/LINCOLN

GM/OPEL

HYUNDAI/KIA

LAND ROVER/JAGUAR

LUXGEN

MASERATI

MAZDA

MITSUBISHI

NISSAN

OPEL

PSA

SMART

SUBARU

SUZUKI

VOLVO

VW/AUDI/SEAT/SKODA





APRILIA

BRP

CFMOTO

DERBI

GILERA

GUZZI

PEUGEOT

PIAGGIO

QJBENELLI

VESPA





1. R/W eeprom/dflash/pflash/Map, reset ECU(Virgin), calibrate mileage, read IMMO pincode, ECU recovery...
2. Support 710+ ECM types(Partial functions require P003 adapter.)
3. Support 210+ TCM types
4. Support 120+ body/other ECU types(AIRBAG, BCM, BSI, CEM, DDM/PDM, DIM, EPS, KeyLess(RFHUB/RFHM), KVM, RFA, SAM...)
5. Support VW DQXXX (TCM) calibrate mileage
6. Support motorcycle Delphi MT05, MT05.2, MT05.3 ECU clone
7. Support motorcycle BRP ME17.8.5 ECU clone (works with P003 adapter)
8. Support Piaggio series engine ECU clone(such as MIU G4 (M4G1))
9. Support intelligent search by brand, model, part No., ECU manufacturer, MCU controller type
10. Support automatic identification
11. Strong help data files
12. All by OBD or Bench mode



More functions are in developing...


DC706 Latest Update Information

TCM
 【Version:V30.41】
 1.Add below models:
 ● HAVAL SIEMENS/CONTINENTAL 7DCT450 TC265 RW INT eeprom, RW INT flash (BENCH);
 ● HYUNDAI VITESCO TAD701 TC275 RW INT eeprom,RW INT flash (BENCH);
 ● KIA VITESCO TAD701 TC275 RW INT eeprom,RW INT flash (BENCH);
 ● HYUNDAI SIEMENS/CONTINENTAL SIM2K-341 TCM(TC1766)+ ECM(MPC561/562)RW INT eeprom,RW INT flash,RW MAPS (BENCH/BOOT);
 ● KIA SIEMENS/CONTINENTAL SIM2K-341 TCM(TC1766)+ECM (MPC561/562)RW INT eeprom,Read/Write INT flash,RW MAPS (BENCH/BOOT);
 ● LAND ROVER ZF 9HP TC1782N RW INT eeprom,RW INT flash (BENCH);
 ● JAGUAR ZF 9HP TC1782N RW INT eeprom,RW INT flash (BENCH);
 ● VOLKSWAGEN AISIN AQ250(09S)R7F701204 RW INT eeprom, RW INT flash (BENCH).

 2.Optimized software.

BODY【Version:V30.37】
1.Details Added:
● Add FORD BCM DELPHI R5F64524 Without demoulding read PinCodeconnect function (OBD/BENCH);
● Add FORD BCM DELPHI R5F64525 Without demoulding read PinCodeconnect function (OBD/BENCH);
● Add VOLVO CEM DELPHI-2015 R5F64524 Without demoulding readPinCode connect function (OBD/BENCH);
● Add VOLVO CEM DELPHI -2015 R5F64525 Without demoulding readPinCode connect function (OBD/BENCH);
● Add VOLVO CEM DELPHI 2015-R5F64524 Without demoulding readPinCode connect function (OBD/BENCH);
● Add VOLVO CEM DELPHI 2015-R5F64525 Without demoulding readPinCode connect function (OBD/BENCH);
·Add VOLVO CEM DELPHI M30882F+95320(25320)Without demouldingread PinCode connect function (OBD/BENCH);
● Add VOLVO CEM LEAR SPC560B60+95320 Without demoulding readPinCode connect function (OBD/BENCH);
● Add VOLVO CEM LEAR SPC560B64+95320 Without demoulding readPinCode connect function (OBD/BENCH).
2.Optimized software.

 ECM
 【Version:V31.10】

 1.Add below models:
 ● ASHOK LEYLAND DELPHI DCM7.1AP LCV TC277T RW INT flash (BENCH);
 ● AUDI BOSCH EDC17CP14 TC1796 RW INT eeprom,RW INT flash, RW EXT flash,Read IMMO data,IMMO Data Decryption,INT eeprom
 Data Convert(CLONE),Mileage Calibration,Write VIN(BOOT);
 ● AUDI CONTINENTAL SIMOS18.1 TC1791 RW INT eeprom,RW INT
 flash (BOOT)(Only support MP001 PROGRAMMER);
 ● AUDI CONTINENTAL SIMOS18.3 TC1791 RW INT eeprom,RW INT
 flash(BO⁰T)(Only support MP001 PROGRAMMER);
 ● BAIC DELPHI MT80 TC1766 RW INT eeprom,RW INT flash (BOOT); -                 --r-                    --\---1
 ● BMW CONTINENTAL MSV90 TC1796 RW All Data (BENCH);
 ● BUICK DELPHI MT60 TC1766 RW INT eeprom,RW INT flash (BO0T);
 ● CHEVROLET DELPHI HV240 RW EXT eeprom,RW EXT flash (BENCH);
 ● CHEVROLET DELPHI MR140 RW EXT eeprom,RW EXT flash (BENCH);
 ● CHEVROLET DELPHI MT60 TC1766 RW INT eeprom,RW INT flash
 (BOOT);
 ● CHEVROLET DELPHI MT80 TC1766 R/W INT eeprom,R/W INT flash
 (BOOT);
 ● DAEWO0 DELPHI HV240 RW EXT eeprom,RW EXT flash (BENCH);
 ● DAEWO0 DELPHI MR140 RW EXT eeprom,RW EXT flash (BENCH);
 ● DEUTZ BOSCH MD1CC878 SPC5898 RW INT eeprom,RW INT flash (BENCH);
 ● FORD CONTINENTAL SID208 TC1797 RW INT eeprom,RW INT flash (BOOT);
 ● FORD DELPHI DCM3.5 MPC5565 RW EXT eeprom,RW INT flash (BOOT);
 ● FORD SIEMENS SID206 MPC561/562 RW MAPS (BENCH);
 ● GEELY DELPHI MT80 TC1766 RW INT eeprom,RW INT flash (BO0T);
 ● GM SIEMENS SIM2K-243 TC1738 RW INT flash(BENCH);
 ● GM SIEMENS/CONTINENTAL D5229F400BB RW EXT flash (BOOT);
 ● GM SIEMENS/CONTINENTAL SIRIUS D3/D429F400BB RW EXT flash (BOOT);
 ● GM SIMTEC 76.129F800BB RW EXT flash (BO0T);
 ● HYUNDAI BOSCH EDC17CP14 TC1796 RW INT eeprom,RW INT flash, RW EXT flash,Write VIN(BO0T);
 ● HYUNDAI BOSCH M7.9.8 ST10F275+95160 RW EXT eeprom,RW INT flash (BENCH/BOOT);
 ● HYUNDAI BOSCH MG7.9.8 ST10F275+95160 RW EXT eeprom,RW INT flash (BOOT);
 ● HYUNDAI CONTINENTAL SIM2K-341 TC1766+MPC561 RW MAPS, RW INT eeprom,RW INT flash (BENCH/BOOT);
 ● HYUNDAI SIEMENS SIM2K-1B 29F400BB RW EXT flash (BOOT);
 ● HYUNDAI SIEMENS SIM2K-243 TC1738 RW INT flash (BENCH);
 ● JAC DELPHI MT60 TC1766 RW INT eeprom,RW INT flash (BOOT);
 ● KIA BOSCH EDC17CP14 TC1796 RW INT eeprom,RW INT flash,RW EXT flash,Write VIN(BOOT);
 ● KIA BOSCH M7.9.8 ST10F275+95160 RW EXT eeprom,RW INT flash (BENCH/BOOT);
 ● KIA BOSCH MG7.9.8 ST10F275+95160 RW EXT eeprom,RW INT flash (BOOT);
 ● KIA CONTINENTAL SIM2K-341 TC1766+MPC561 RW MAPS,RW INT eeprom,RW INT flash (BENCH/BOOT);
 ● KIA SIEMENS SIM2K-1B 29F400BB RW EXT flash (BO0T);
 ● KIA SIEMENS SIM2K-243 TC1738 RW INT flash (BENCH);
 ● LANDROVER CONTINENTAL SID208 TC1797 RW INT eeprom,RW INT flash (BOOT);
 ● LUXGEN DELPHI MT80 TC1766 RW INT eeprom,RW INT flash (BO0T);
 ● MAZDA CONTINENTAL SID208 TC1797 RW INT eeprom,RW INT flash
 (BOOT);
 ● OPEL SIEMENS/CONTINENTAL D5229F400BB RW EXT flash (BOOT);
 ● OPEL SIEMENS/CONTINENTAL SIRIUS D3/D429F400BB RW EXT flash (BOOT);
 ● OPEL SIMTEC 76.129F800BB RW EXT flash (BOOT);
 ● PORSCHE BOSCH EDC17CP14 TC1796 RW INT eeprom,RW INT flash,RW EXT flash,Read IMMO data,IMMO Data Decryption,INT eeprom Data Convert(CLONE),Mileage Calibration,Write VIN (BOOT);
 ● PORSCHE CONTINENTAL SDI6 TC1796+95128 RW EXT eeprom,RW INT flash (BENCH);
 ● PORSCHE CONTINENTAL SDI7 TC1796+95128 RW EXT eeprom,RW INT flash (BENCH);
 ● PORSCHE CONTINENTAL SDl8 TC1796+95128 RW EXT eeprom,RW INT flash (BENCH);
 ● PORSCHE CONTINENTAL SIMOS18.1 TC1791 RW INT eeprom,RW INT flash (BO0T)(Only support MP001 PROGRAMMER);
 ● SEAT BOSCH EDC17CP14 TC1796 RW INT eeprom,RW INT flash, RW EXT flash,Read IMMO data,IMMO Data Decryption,INT eeprom Data Convert(CLONE),Mileage Calibration,Write VIN(BOOT);
 ● SEAT CONTINENTAL SIMOS18.1 TC1791 RW INT eeprom,RW INT flash (BO0T)(Only support MP001 PROGRAMMER);
 ● SKODA BOSCH MG1CA811 SPC5898 RW INT eeprom,RW INT flash (BENCH);
 ● SKODA CONTINENTAL SIMOS18.1 TC1791 RW INT eeprom,RW INT flash (BO0T)(Only support MP001 PROGRAMMER);
 ● SKODA CONTINENTAL SIMOS18.3 TC1791 RW INT eeprom,RW INT flash (BOOT)(Only support MP001 PROGRAMMER);
 ● TATA BOSCH ME17.9.71 TC1724N RW INT eeprom,RW INT flash (BENCH);
 ● VOLKSWAGEN BOSCH EDC17CP14 TC1796 RW INT eeprom,RW INT flash,RW EXT flash,Read IMMO data,IMMO Data Decryption,INT eeprom Data Convert(CLONE),Mileage Calibration,Write VIN(BOOT);
 ● VOLKSWAGEN BOSCH MG1CA811 SPC5898 RW INT eeprom,RW INT flash (BENCH);
 ● VOLKSWAGEN CONTINENTAL SIMOS18.1 TC1791 RW INT eeprom, RW INT flash (BOOT)(Only support MP001 PROGRAMMER);
 ● VOLKSWAGEN CONTINENTAL SIMOS18.3 TC1791 RW INT eeprom, RW INT flash (BOOT)(Only support MP001 PROGRAMMER).
 2.Add below models:
 ● BAIC BOSCH ME17.U.6 TC1728 Write VIN(BENCH);
 ● BENZ DELPHI CRD2.XX MPC5566+25LC256 Reset Virgin (BENCH);
 ● BENZ DELPHI CRD3.E1 TC1793+25LC256 Reset Virgin (BENCH);
 ● BENZ DELPHI CRD3.F1 TC1793+25LC256 Reset Virgin (BENCH);
 ● BENZ DELPHI CRD3.XX TC1797+25LC256 Reset Virgin(BENCH);
 ● BENZ DELPHI CRD3E.1 TC1793+25LC256 Reset Virgin(BENCH);
 ● BENZ DELPHI CRD3P.BO TC1793+25LC256 Reset Virgin (BENCH);
 ● BENZ DELPHI CRD3P.C0 TC1793+25LC256 Reset Virgin(BENCH);
 ● BENZ DELPHI CRD3P.D1 TC1793+25LC256 Reset Virgin(BENCH);
 ● BENZ DELPHI CRD3P.GO TC1793+25LC256 Reset Virgin(BENCH);
 ● BENZ DELPHI CRD3X.X TC1793+25LC256 Reset Virgin (BENCH);
 ● BENZ SIEMENS/CONTINENTAL SIM271DE TC1796+ST95128 Reset Virgin (BENCH);
 ● BENZ SIEMENS/CONTINENTAL SIM271KE TC1796 Reset Virgin
 (BENCH);
 ● BOSCH MEDC17 TC17XX series INT eeprom CS (BENCH);
 ●CHANGAN BOSCH ME17.U.6 TC1728 Write VIN(BENCH);
 ● CHERY BOSCH ME17.U.6 TC1728 Write VIN(BENCH);
 ●CITROEN BOSCH EDC17C60 TC1793 Read PinCode (BENCH);
 ● FIAT BOSCH ME17.9.51 TC1766 Write VIN(BENCH);
 ●GEELY BOSCH ME17.U.6 TC1728 Write VIN(BENCH);
 ● GM/HYUNDAI/KIA SIEMENS SIM2K-243 TC1738 INT flash CS (BENCH);
 ● GREATWALL BOSCH ME17.U.6 TC1728 Write VIN(BENCH);
 ● HYUNDAI BOSCH MED17.9.8 TC1767 Write VIN (BENCH);
 ● HYUNDAI BOSCH MEG17.9.13 TC1766 Write VIN(BENCH);
 ● JAC BOSCH ME17.U.6 TC1728 Write VIN(BENCH);
 ● JAGUAR BOSCH MED17.9.8 TC1767 Write VIN(BENCH);
 ● JMC BOSCH EDC17C81 TC1782 Write VIN(BENCH);
 ● KIA BOSCH MED17.9.8 TC1767 Write VIN(BENCH);
 ● KIA BOSCH MEG17.9.13 TC1766 Write VIN (BENCH);
 ● LIFAN BOSCH ME17.U.6 TC1728 Write VIN(BENCH);
 ● MAHINDRA BOSCH EDC17C81 TC1782 Write VIN(BENCH);
 ● MG BOSCH ME17.U.6 TC1728 Write VIN(BENCH);
 ● PEUGEOT BOSCH EDC17C60 TC1793 Read PinCode (BENCH);
 ● SAIC BOSCH ME17 MT TC1728 Write VIN(BENCH);
 ● SAIC BOSCH ME17.U.6 TC1728 Write VIN(BENCH);
 ● SEAT BOSCH EDC17U01 TC1766 Mileage Calibration,Write VIN (BENCH);
 ● SKODA BOSCH EDC17U01 TC1766 Mileage Calibration,Write VIN (BENCH);
 ● SUZUKI BOSCH ME17.9.51 TC1766 Write VIN(BENCH);
 ·VOLKSWAGEN BOSCH EDC17U01 TC1766 Mileage Calibration,Write VIN(BENCH);
 ● VOLKSWAGEN BOSCH ME17.5.6 TC1767 Write VIN(BENCH)

Product Specifications:


Operation system	Android 5.1.1
CPU	RK3128 quad-core ARM cortex A7
Battery	3700mA, rechargeable polymer lithium battery
Extension memory card	32G micro SD (TF) card supported
Storage capacity	16GB
LCD	7.0 inch
LCD resolution	1024*600
Touch screen	Capacitive touch screen
Wifi	Supported
Working temperature	-20℃~55℃ (14℉~131℉)
Storage temperature	-20℃~70℃ (-4℉~158℉)
Weight	About 1.3kg
Dimension	243mm*148mm*36mm

Package Includes:

1pc x DC706 Main Unit
1pc x main cable
1pc x P004 adapter
1pc x P004 ECU clone jumper
1pc x 12V2A charger
1pc x  BENCH-B V2 Cable
